Eco-King Ultimate Commercial Boiler

2 reviews
96% efficient Cascade to 16 BACnet / Modbus

96% efficient commercial power in three sizes (299, 399, 499k BTU), cascading up to 16 units with racking systems and low-loss headers, and speaking BACnet/Modbus to your BMS natively.

Efficiency 96%
Outputs 299,000 to 499,000 BTU/h per unit
Cascading Up to 16 units, serviceable one at a time
Integration BACnet / Modbus native
Pricing
Contact one of our authorized distributors near you for pricing.
Contact Us for Pricing Find a Distributor

Register online to activate warranty

Spec'ing a project? Racking and cascade kits are catalogue items, and our team supports BMS integration: talk to us.

Overview

Redundancy by design.Serviceable one at a time.

Cascade Ultimates share the load, rotate lead-lag duty and keep the building warm while any single unit is serviced. Racking systems and low-loss headers make the mechanical room layout a catalogue exercise, not a custom fabrication.

✓Cascade up to 16 units with lead-lag rotation
✓Racking systems and low-loss headers off the shelf
✓Native BACnet / Modbus for BMS integration

High efficient commercial wall-hung boilers.

  • Up to 96% high-efficient wall hung condensing boilers with European state of the art technology
  • 3 sizes and two models. Boiler and Volume water heater in 300, 400 and 500 MBH
  • ASME Stainless steel heat exchanger
  • Cascade up to 16 boilers in a row
  • Racking systems available from 2 to 4 units on one rack with Low Loss Header. Plug & Play
  • 3 in 1 venting adapters included. Vent directly off the top with (C)PVC, PP or Stainless Steel
  • Wi-Fi with mobile app capability (extra accessory)
  • Outdoor sensor, Wi-Fi, Bacnet/Modbus connections on all boilers
  • Multiple pump connections with two temperature capability: DHW tank and Heating
Grants & Rebates

This product qualifies for a $1,000 FortisBC rebate. Click here for details.

Models & Sizes Available

Model BTU
EK 299 CHB 295,000 BTU/Hr
EK 399 CHB 399,000 BTU/Hr
EK 499 CHB 490,000 BTU/Hr
Eco King Products OverviewEco-King Ultimate Commercial Boiler

Specifications

Efficiency 96%
Outputs 299,000 to 499,000 BTU/h per unit
Cascading Up to 16 units, serviceable one at a time
Integration BACnet / Modbus native
Application Multi-unit residential · commercial · institutional
Certification NRCan approved · CSA
Detailed I/O Ratings See spec sheet in the Downloads hub
Water connections 1 1/2" NPT
Gas connection 1"
Dimensions (HxWxD) 33" x 17" x 21"
Weight 174 lbs / 79 kgs
Intake / Exhaust 100mm / 4" and 6" for 499 model
Documents

Warranty & Manuals

Limited Lifetime Warranty

Components Covered Residential Installations Commercial Installations
Heat Exchanger 0-5 Years – 100%
6-10 Years – 50%
11 + Years – 25%
0-5 Years – 100%
6-10 Years – 50%
All other components 5 Years 2 Years
Components required for recommended maintenance Not covered: Ignitors, refractory insulation, combustion chamber gaskets Not Covered Ignitors, refractory insulation, combustion chamber gaskets

Limited Lifetime Warranty

Register online to activate full coverage. Two minutes per unit.

Register your unit

Fast and reliable service

Amazing service. service tech (Gerry) was able to help me troubleshoot our boiler problem and get it up and running in no time.

Jolaine Giammarco · Richmond · British Columbia

$10,000 savings in gas alone

We removed two 400,000 BTU atmospheric boilers, and installed two Eco King 200,000 BTU Boilers.

In just under 1 year, our savings have roughly been $10,000 in gas alone.

Fredrick · NorthSide Church, Coquitlam · British Columbia
